JL Audio A60-H 17W RMS x 4 Hideaway 4-Zone Marine Stereo with DSP, Bluetooth 6.1 & NMEA 2000 (010-04305-00)

The A60-H provides modern marine entertainment without a visible stereo faceplate. Designed for concealed mounting, this advanced hideaway head unit combines Bluetooth 6.1 LE Audio, integrated digital signal processing, four-zone audio management, and NMEA 2000 networking with a built-in four-channel Class D amplifier.

Key Features

• Four independent audio zones with left/right and mono subwoofer preouts for each zone
• 17W RMS x 4 built-in Class D power at 4 ohms and 14.4V
• Bluetooth 6.1 LE Audio streaming and Garmin Audio app control
• DSP configuration and Easy Tune via Garmin Audio app
• NMEA 2000 integration for compatible Garmin MFDs and supported wired controls
• USB-C, AM/FM, DAB+, and auxiliary audio source support
• IPX6/IPX7-rated enclosure when correctly installed; designed for concealed marine mounting

Detailed Technical Specifications

• Speaker Power: 17W RMS x 4 @ 4 ohms
• Audio Zones: 4 preamp zones; 2 zones with internally amplified channels
• Bluetooth: Version 6.1 with LE Audio
• Audio Sources: AM/FM, USB-C, Bluetooth, auxiliary; DAB+ support depends on region
• NMEA 2000: 1 port, LEN 1 (50mA)
• USB: USB-C (USB 2.0)
• Supply Voltage: 10.8–16V DC
• Fuse: 15A
• Dimensions: 5.86" W x 5.11" H x 2.50" D
• Weight: 1.22 lbs (560g)
• Ingress Rating: IPX6/IPX7 with proper installation
• Operating Temperature: 32°F–122°F (0°C–50°C)

Compatibility

Works with compatible Garmin chartplotters over NMEA 2000, the Garmin Audio app, and supported JL Audio remote-control accessories such as NRX-300 and R5. Network accessories and external amplifiers for additional zones are sold separately.

Installation Notes

This is a hideaway unit and has no built-in helm display. Plan a compatible external control method. Only two zones have internally amplified speaker outputs; four zones have preamplifier outputs.

What's in the Box

• JL Audio A60-H hideaway head unit
• Power/speaker harness
• Zone 1 and 2 harness
• Zone 3 and 4 harness
• Mounting hardware
• Documentation
